SPECIFICATIONS

Network

• Technology: GSM / CDMA / HSPA / EVDO / LTE
• 2G bands: GSM 850 / 900 / 1800 / 1900 - A1661, A1784
• CDMA 800 / 1900 / 2100 - A1661
• 3G bands: HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - A1661, A1784
• CDMA2000 1xEV-DO & TD-SCDMA - A1661
• 4G bands: LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 13(700), 17(700), 18(800), 19(800), 20(800), 25(1900), 26(850), 27(800), 28(700), 29(700), 30(2300), 38(2600), 39(1900), 40(2300), 41(2500) - A1661, A1784
• Speed: HSPA 42.2/5.76 Mbps, LTE Cat9 450/50 Mbps, EV-DO Rev.A 3.1 Mbps
• GPRS: Yes
• EDGE: Yes

SIM

• Nano-SIM
• IP67 certified - dust and water resistant
• Water resistant up to 1 meter and 30 minutes
• Apple Pay (Visa, MasterCard, AMEX certified)

Display

• Type: LED-backlit IPS LCD, capacitive touchscreen, 16M colors
• Size: 5.5 inches (~67.7% screen-to-body ratio)
• Resolution: 1080 x 1920 pixels (~401 ppi pixel density)
• Multitouch: Yes
• Protection: Ion-strengthened glass, oleophobic coating
• Wide color gamut display
• 3D Touch display & home button
• Display Zoom

Platform

• OS: iOS 10.0.1, upgradable to iOS 10.0.2
• Chipset: Apple A10 Fusion
• CPU: Quad-core 2.23 GHz
• GPU: (six-core graphics)

Memory

• Card slot: No
• Internal: 3 GB RAM

Camera

• Primary: 12 MP, (28mm, f/1.8, OIS & 56mm, f/2.8), phase detection autofocus, 2x optical zoom, quad-LED (dual tone) flash
• Features: Geo-tagging, simultaneous 4K video and 8MP image recording, touch focus, face/smile detection, HDR (photo/panorama)
• Video: 2160p@30fps, 1080p@30/60/120fps, 720p@240fps
• Secondary: 7 MP, f/2.2, 32mm, 1080p@30fps, 720p@240fps, face detection, HDR, panorama

Sound

• Alert types: Vibration, proprietary ringtones
• Loudspeaker: Yes, with stereo speakers
• 3.5mm jack: No
• Active noise cancellation with dedicated mic
• Lightning to 3.5 mm headphone jack adapter incl.

COMMS

• WLAN: Wi-Fi 802.11 a/b/g/n/ac, dual-band, hotspot
• Bluetooth: v4.2, A2DP, LE
• GPS: Yes, with A-GPS, GLONASS
• NFC: Yes (Apple Pay only)
• Radio: No
• USB: v2.0, reversible connector

Features

• Sensors: Fingerprint, accelerometer, gyro, proximity, compass, barometer
• Messaging: iMessage, SMS (threaded view), MMS, Email, Push Email
• Browser HTML5 (Safari)
• Java: No
• Siri natural language commands and dictation
• iCloud cloud service
• MP3/WAV/AAX+/AIFF/Apple Lossless player
• MP4/H.264 player
• Audio/video/photo editor
• Document editor

Battery

• Non-removable Li-Ion 2900 mAh battery (11.1 Wh)
• Stand-by: Up to 384 h (3G)
• Talk time: Up to 21 h (3G)
• Music play: Up to 60 h

Status

• Original iPhone 7 Plus
